– 9 –
Schematic
Location
Part No.
Description
CCAAPPAACCIITTOORRSS
C016 CK1E105KGMBNG CERAMIC 1U K 25V
C017 CEXLB1C222VDJ ELECT 2200U M 16V
C018 CK1A105KLZBNG CERAMIC 1U K 10V
C019 CK1A105KLZBNG CERAMIC 1U K 10V
C020 CEXLB1C102VDJ ELECT 1000U M 16V
C021 CK1A105KLZBNG CERAMIC 1U K 10V
C022 CK1A105KLZBNG CERAMIC 1U K 10V
C023 CK1A105KLZBNG CERAMIC 1U K 10V
C024 CK1E474KLZBNG CERAMIC 0.47U K 25V
C025 CK1H104KLZBNG CERAMIC 0.1U K 50V
C027 CK1E224KLZBNG CERAMIC 0.22U K 25V
C028 CK1A105KLZBNG CERAMIC 1U K 10V
C029 CK1E474KLZBNG CERAMIC 0.47U K 25V
C030 CK1H104KLZBNG CERAMIC 0.1U K 50V
C031 CEXLB1H100VDJ ELECT 10U M 50V
C032 CK1E105KGMBNG CERAMIC 1U K 25V
C033 CK1A105KLZBNG CERAMIC 1U K 10V
C035 CK1A105KLZBNG CERAMIC 1U K 10V
C038 CK1A105KLZBNG CERAMIC 1U K 10V
C039 CK1A105KLZBNG CERAMIC 1U K 10V
C040 CK1E474KLZBNG CERAMIC 0.47U K 25V
C041 CK1H104KLZBNG CERAMIC 0.1U K 50V
C043 CK1E224KLZBNG CERAMIC 0.22U K 25V
C044 CK1E474KLZBNG CERAMIC 0.47U K 25V
C045 CK1H104KLZBNG CERAMIC 0.1U K 50V
C047 CK1E105KGMBNG CERAMIC 1U K 25V
C048 CK1H104KLZBNG CERAMIC 0.1U K 50V
C049 CK1H104KLZBNG CERAMIC 0.1U K 50V
C050 CK1H104KLZBNG CERAMIC 0.1U K 50V
C051 CK1H104KLZBNG CERAMIC 0.1U K 50V
C800 CK1A105KLZBNG CERAMIC 1U K 10V
C801 CK1H104KLZBNG CERAMIC 0.1U K 50V
C802 CC1H470JLZCNG CERAMIC 47P J 50V
C804 CEXLB0J221VDJ ELECT 220U M 6.3V
C805 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C806 CC1H270JLZCNG CERAMIC 27P J 50V
C807 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C813 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C815 CC1H270JLZCNG CERAMIC 27P J 50V
C816 CC1H270JLZCNG CERAMIC 27P J 50V
C817 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C818 CC1H220JLZCNG CERAMIC 22P J 50V
C819 CC1H220JLZCNG CERAMIC 22P J 50V
C1000 CEXLB1V470VDJ ELECT 47U M 35V
C1002 CK1A105KLZBNG CERAMIC 1U K 10V
C1004 CK1A105KLZBNG CERAMIC 1U K 10V
C1006 CK1A105KLZBNG CERAMIC 1U K 10V
C1008 CK1A105KLZBNG CERAMIC 1U K 10V
C1010 CK1A105KLZBNG CERAMIC 1U K 10V
C1012 CK1A105KLZBNG CERAMIC 1U K 10V
C1014 CK1A105KLZBNG CERAMIC 1U K 10V
C1016 CK1A105KLZBNG CERAMIC 1U K 10V
C1600 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1601 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1602 CEXLB1V471VDJ ELECT 470U M 35V
C1603 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1604 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1605 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1606 CK1A105KLZBNG CERAMIC 1U K 10V
C1607 CEXLB0J102VDJ ELECT 1000U M 6.3V
C1608 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1609 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1611 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1612 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1616 CK1H473KLZBNG CERAMIC 0.047U K 50V
C1620 CK0J106KGMBNG CERAMIC 10U Z 6.3V
C1622 CEXLB0J221VDJ ELECT 220U M 6.3V
C1623 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1624 CEXLB1V471VDJ ELECT 470U M 35V
C1640 CEXLB1C101VDJ ELECT 100U M 16V
C1641 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1642 CK1H223KLZBNG CERAMIC 0.022U K 50V
C1643 CK1A105KLZBNG CERAMIC 1U K 10V
C1645 CK1H472KLZBNG CERAMIC 4700P K 50V
C1646 CK1A105KLZBNG CERAMIC 1U K 10V
C1647 CEXLB0J102VDJ ELECT 1000U M 6.3V
C1670 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1672 CEXLB1V470VDJ ELECT 47U M 35V
C1673 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1674 CEXLB1V471VDJ ELECT 470U M 35V
C1680 CEXLB1V471VDJ ELECT 470U M 35V
C1681 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1682 CEXLB1C102VDJ ELECT 1000U M 16V
C1683 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1687 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1691 CK1H104KLZBNG CERAMIC 0.1U K 50V
C1692 CK1H102KLZBNG CERAMIC 1000P K 50V
C1836 CK1H103KLZBNG CERAMIC 0.01U K 50V
C1837 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C2403 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C2404 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C2405 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C2406 CEXLB0J221VDJ ELECT 220U M 6.3V
C2408 CK1A105KLZBNG CERAMIC 1U K 10V
C2410 CK1A105KLZBNG CERAMIC 1U K 10V
C2440 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C2445 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C3902 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C3904 CK0J106KGMBNG CERAMIC 10U Z 6.3V
C5500 CK0J106KGMBNG CERAMIC 10U Z 6.3V
C5501 CK1A105KLZBNG CERAMIC 1U K 10V
C5502 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5503 CK1A105KLZBNG CERAMIC 1U K 10V
C5504 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5505 CK0J106KGMBNG CERAMIC 10U Z 6.3V
C5506 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5507 CK1H104KLZBNG CERAMIC 0.1U K 50V
C5508 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5509 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5510 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C5511 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
Schematic
Location
Part No.
Description
