– 18 –
Schematic
Location
Part No.
Description
Schematic
Location
Part No.
Description
MMIISSCCEELLLLAANNEEOOUUSS
A3900 1AV4U20C11701 “UNIT,REMOCON RECEIVER”
A6100 1AV4F1BAZ0090 “TUNER,U/V”
El901 1AV4T40C04900 LCD(T260XW02 VQ)
K1003 1LB4J31B01101 “TERMINAL, BOARD”
K1004 1LB4J12B11700 “JACK,RCA-9”
K1005 1LB4J12B11600 “JACK,RCA-6”
K2400 1LB4J11B0630N “SOCKET,D-SUB 15P”
K2401 1LB4J12B11900 “JACK,PHONE D3.6”
K8C 1AV4J10FT130N “PLUG,PWB 13P”
K8CTRA 1AV4J10AU035N “PLUG,3P”
K8FRA 1AV4J10EA063N “PLUG,6P”
K8L 1AV4J10AU055N “PLUG,5P”
KSP 1AV4J10EA043N “PLUG,4P”
KUSB 1LB4J11B0550N “SOCKET,USB 4P”
K5LV 1AV4J10XE300G “PLUG,30P”
K6500 1AV4J11B8591G “SOCKET,IF(HDMI) 19P”
K6550 1AV4J11B8591G “SOCKET,IF(HDMI) 19P”
K19CTRA 1AV4J10AV033N “PLUG,3P”
K39K 1AV4J10EA063N “PLUG,6P”
PB001 1LG4B10Y03000 “PWB,MAIN ,N7BE”
PB1900 1AA4B10N23200 “PWB,CONTROL X16 N7AE”
PB3900 1AA4B10N23200 “PWB,CONTROL X16 N7AE”
SP901 1LB4A10B11500 “SPEAKER,8”
SP902 1LB4A10B11500 “SPEAKER,8”
WK5LV 1LB4W30B16500 “CORD ,30P-30P(LVDS)”
W901 1AV4W10B17904 “CORD,POWER-2.0MK-VTR-02”
PPOOWWEERR BBOOAARRDD
U901 1AV4U20C38400 “UNIT,POWER”
