- 4 -
Do not remove the pick-up from base mechanism because of
adjustment difficulty.
GREASE
CDF-409Z or
SF-106B
GREASE
CDF-409Z or SF-106B
GREASE
CDF-409Z or
SF-106B
: Clean the groove by alcohol well.
A
A
A
G-SANKOL
G-SANKOL
G-SANKOL
G-SANKOL
GREASE
EM-30LG
GREASE
EM-30LG
6. Base mechanism mounting parts.
7. Base mechanism parts.
8. Tray parts.
MECHANISM REPLACEMENT
