— 8 —
MECHANICAL DISASSEMBLY (CONT.)
SPEAKER REMOVAL
Lift both speakers from cabinet.
MOUNTING BRACKET AND SPEAKER REMOVAL
Remove 11 screws to take off the mouniting bracket and the left and
right speakers.
Mounting
Bracket
