— 12 —
Schematic
Location
Part No.
Description
Schematic
Location
Part No.
Description
CAPACITORS
C001 CPXLB1C100YAJ NP-ELECT 10U M 16V
CPXLB1C100ZAJ NP-ELECT 10U M 16V
C002 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C006 CEXLB1H100VDJ ELECT 10U M 50V
C006 CEXLB1H100WAJ ELECT 10U M 50V
C007 CEXLB1V470VDJ ELECT 47U M 35V
CEXLB1V470WAJ ELECT 47U M 35V
C008 CK1H102KLZBNG CERAMIC 1000P K 50V
C009 CK1H102KLZBNG CERAMIC 1000P K 50V
C010 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C011 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C013 CPXLB1C100YAJ NP-ELECT 10U M 16V
C013 CPXLB1C100ZAJ NP-ELECT 10U M 16V
C015 CEXLB1C222VDJ ELECT 2200U M 16V
C016 CEXLB1H100VDJ ELECT 10U M 50V
C016 CEXLB1H100WAJ ELECT 10U M 50V
C017 CEXLB1H100VDJ ELECT 10U M 50V
CEXLB1H100WAJ ELECT 10U M 50V
C018 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C019 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C601 CGXAV27474DDN MT-POLYEST 0.47U M 275V
C602 CGXAV27474DDN MT-POLYEST 0.47U M 275V
C681 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C684 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C697 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C705 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C706 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C710 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C723 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C800 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C804 RGF1003JTCANL MT-GLAZE 100K JA 1/10W
C805 CC1H220JLZCNG CERAMIC 22P J 50V
C806 CC1H220JLZCNG CERAMIC 22P J 50V
C807 CK1H103ZLZFNG CERAMIC 0.01U Z 50V
C811 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C813 CEXLB1V470VDJ ELECT 47U M 35V
CEXLB1V470WAJ ELECT 47U M 35V
C814 CK1H222KLZBNG CERAMIC 2200P K 50V
C815 CC1H220JLZCNG CERAMIC 22P J 50V
C816 CC1H220JLZCNG CERAMIC 22P J 50V
C820 CK1H103ZLZFNG CERAMIC 0.01U Z 50V
C825 CC1H470JLZCNG CERAMIC 47P J 50V
C826 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C827 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C829 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C834 CEXLB0J221VDJ ELECT 220U M 6.3V
CEXLB0J221WAJ ELECT 220U M 6.3V
C835 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C836 CC1H120JLZCNG CERAMIC 12P J 50V
C837 CC1H120JLZCNG CERAMIC 12P J 50V
C839 CK1H103ZLZFNG CERAMIC 0.01U Z 50V
C840 CK1H333KLZBNG CERAMIC 0.033U K 50V
C841 CEXLB1H2R2VDJ ELECT 2.2 U M 50V
CEXLB1H2R2WAJ ELECT 2.2U M 50V
C842 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1000 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1001 CEXLB1H100VDJ ELECT 10U M 50V
CEXLB1H100WAJ ELECT 10U M 50V
C1002 CEXLB1H100VDJ ELECT 10U M 50V
CEXLB1H100WAJ ELECT 10U M 50V
C1003 CEXLB1H4R7VDJ ELECT 4.7 U M 50V
CEXLB1H4R7WAJ ELECT 4.7U M 50V
C1004 CEXLB1H4R7VDJ ELECT 4.7 U M 50V
CEXLB1H4R7WAJ ELECT 4.7U M 50V
C1011 CEXLB1H4R7VDJ ELECT 4.7 U M 50V
CEXLB1H4R7WAJ ELECT 4.7U M 50V
C1012 CEXLB1H4R7VDJ ELECT 4.7 U M 50V
CEXLB1H4R7WAJ ELECT 4.7U M 50V
C1013 CEXLB1H4R7VDJ ELECT 4.7 U M 50V
CEXLB1H4R7WAJ ELECT 4.7U M 50V
C1014 CEXLB1H4R7VDJ ELECT 4.7 U M 50V
CEXLB1H4R7WAJ ELECT 4.7U M 50V
C1015 CEXLB1H4R7VDJ ELECT 4.7 U M 50V
CEXLB1H4R7WAJ ELECT 4.7U M 50V
C1016 CEXLB1H4R7VDJ ELECT 4.7 U M 50V
CEXLB1H4R7WAJ ELECT 4.7U M 50V
C1017 CEXLB1H4R7VDJ ELECT 4.7 U M 50V
CEXLB1H4R7WAJ ELECT 4.7U M 50V
C1201 CEXLB1V470VDJ ELECT 47U M 35V
CEXLB1V470WAJ ELECT 47U M 35V
C1202 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1205 CEXLB1V470VDJ ELECT 47U M 35V
CEXLB1V470WAJ ELECT 47U M 35V
C1251 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1600 CEXLB1E102VDJ ELECT 1K U M 25V
C1601 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1603 CK1A105ZLZFNG CERAMIC 1P Z 10V
C1604 CK0J475KLZBNG CERAMIC 4.7U K 6.3V
C1606 CEXLB0J102VDJ ELECT 1000U M 6.3V
CEXLB0J102WAJ ELECT 1000U M 6.3
C1610 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1611 CK1A105ZLZFNG CERAMIC 1P Z 10V
C1613 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1614 CEXLB0J221VDJ ELECT 220U M 6.3V
CEXLB0J221WAJ ELECT 220U M 6.3V
C1615 CEXLB0J221VDJ ELECT 220U M 6.3V
CEXLB0J221WAJ ELECT 220U M 6.3V
C1618 CK1A105ZLZFNG CERAMIC 1P Z 10V
C1619 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1620 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1623 CEXLB1H100VDJ ELECT 10U M 50V
CEXLB1H100WAJ ELECT 10U M 50V
C1630 CEXLB1C101VDJ ELECT 100U M 16V
CEXLB1C101WAJ ELECT 100U M 16V
C1631 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1632 CK1H104ZLZFNG CERAMIC 0.1U Z 50V
C1633 CEXLB0J102VDJ ELECT 1000U M 6.3V
