Sanyo DS31520 Service Manual

— 17 —
405 041 6507 TR 2SC2621-D-RA
405 041 6705 TR 2SC2621-E-RA
405 066 9903 TR 2SC2688(1)-K
405 067 0008 TR 2SC2688(1)-L
405 067 0107 TR 2SC2688(1)-M
Q831 406 000 6804 TR 2SA1015-GR(SAN)
405 001 7407 TR 2SA1015-O(SAN)
405 001 7605 TR 2SA1015-Y(SAN)
405 004 3109 TR 2SA564A-Q(CU)
405 004 3208 TR 2SA564A-R(CU)
405 151 3304 TR 2SA608NF-NPA
405 006 1707 TR 2SA933S-Q
405 006 1806 TR 2SA933S-R
R001 401 027 8602 CARBON 8.2K JA 1/6W
R002 401 027 8602 CARBON 8.2K JA 1/6W
R003 401 162 2800 MT-GLAZE 1.8K JA 1/10W
R004 401 162 2800 MT-GLAZE 1.8K JA 1/10W
R005 401 150 5905 MT-GLAZE 10K JA 1/10W
R006 401 023 1706 CARBON 820 JA 1/4W
R012 401 027 2600 CARBON 5.6K JA 1/6W
★ R106 401 009 2000 CARBON 27K JA 1/2W
R131 401 256 1702 MT-GLAZE 33K JA 1/10W
R133 401 255 6401 MT-GLAZE 3K JA 1/10W
R135 401 150 6001 MT-GLAZE 0.000 ZA 1/10W
R137 401 150 6209 MT-GLAZE 1K JA 1/10W
R142 401 256 1702 MT-GLAZE 33K JA 1/10W
R143 401 150 6209 MT-GLAZE 1K JA 1/10W
R151 401 152 3206 MT-GLAZE 330 JA 1/10W
R161 401 150 5806 MT-GLAZE 100K JA 1/10W
R162 401 150 5806 MT-GLAZE 100K JA 1/10W
R163 401 256 0002 MT-GLAZE 120 JA 1/10W
R164 401 150 6209 MT-GLAZE 1K JA 1/10W
R166 401 256 7506 MT-GLAZE 390 JA 1/10W
R167 401 162 2701 MT-GLAZE 180 JA 1/10W
R201 401 026 9600 CARBON 470 JA 1/6W
R208 401 150 6209 MT-GLAZE 1K JA 1/10W
R212 401 256 7100 MT-GLAZE 680K JA 1/10W
R251 401 256 5304 MT-GLAZE 56K JA 1/10W
R252 401 256 3607 MT-GLAZE 15K JA 1/10W
R271 401 162 3401 MT-GLAZE 39K JA 1/10W
R272 401 027 5502 CARBON 6.8K JA 1/6W
R273 401 024 7400 CARBON 10K JA 1/6W
R274 401 162 4101 MT-GLAZE 5.6K JA 1/10W
R275 401 256 6608 MT-GLAZE 68K JA 1/10W
R276 401 024 9701 CARBON 12K JA 1/6W
R280 401 026 4902 CARBON 330K JA 1/6W
R281 401 150 5905 MT-GLAZE 10K JA 1/10W
R284 401 026 9303 CARBON 47 JA 1/6W
R287 401 255 6500 MT-GLAZE 100 JA 1/10W
R288 401 255 6500 MT-GLAZE 100 JA 1/10W
R289 401 255 6500 MT-GLAZE 100 JA 1/10W
R301 401 150 6001 MT-GLAZE 0.000 ZA 1/10W
R311 401 024 6700 CARBON 100 JA 1/6W
R312 401 162 4101 MT-GLAZE 5.6K JA 1/10W
R321 401 150 5905 MT-GLAZE 10K JA 1/10W
R323 401 256 4109 MT-GLAZE 56 JA 1/10W
R324 401 162 4101 MT-GLAZE 5.6K JA 1/10W
R326 401 256 4109 MT-GLAZE 56 JA 1/10W
R353 401 024 7400 CARBON 10K JA 1/6W
★ R401 401 012 4503 CARBON 100 JA 1/4W
★ R402 401 013 4205 CARBON 120 JA 1/4W
R404 401 024 6700 CARBON 100 JA 1/6W
R405 401 162 4101 MT-GLAZE 5.6K JA 1/10W
★ R406 401 010 8305 CARBON 5.6K JA 1/2W
★ R407 401 068 4700 OXIDE-MT 4.7K JA 2W
★ R413 402 067 3305 WIRE WOUND 4.7 KA 5W
402 075 5704 WIRE WOUND 4.7 KA 5W
★ R418 401 009 1607 CARBON 2.7K JB 1/2W
★ R421 401 148 7201 MT-FILM 1.8K FA 1/6W
★ R422 401 052 6802 MT-FILM 10K FA 1/6W
★ R423 401 264 9301 MT-GLAZE 3.3K FA 1/10W
R426 401 256 6905 MT-GLAZE 680 JA 1/10W
R428 401 025 1902 CARBON 15K JA 1/6W
R441 401 024 7004 CARBON 1K JA 1/6W
R442 401 150 5905 MT-GLAZE 10K JA 1/10W
R443 401 026 9907 CARBON 4.7K JA 1/6W
R444 401 025 4606 CARBON 18K JA 1/6W
R449 401 053 3206 MT-FILM 4.7K FA 1/6W
R461 401 026 4902 CARBON 330K JA 1/6W
R462 401 025 8208 CARBON 22K JA 1/6W
★ R463 401 006 8807 CARBON 1.8 JA 1/2W
R464 401 025 4606 CARBON 18K JA 1/6W
★ R465 401 006 8401 CARBON 1.5 JA 1/2W
R466 401 026 7408 CARBON 39K JA 1/6W
★ R467 401 065 3706 OXIDE-MT 1.2K JA 2W
Schematic
Location
Part No.
Description
Schematic
Location
Part No.
Description
Tolerance Symbols:
A...0.05% B...0.1% C...25%
D...0.5% F...1% G...2%
J...5% K...10% M...20%
P...+5 -15%

Rated Value, ohms:
K...1,000 M...1,000,000
Material:
CARBON .............
MT-FILM ..............
OXIDE-MT ...........
SOLID ..................
MT-GLAZE ...........
WIRE WOUND .....
CERAMIC RES ....
FUSIBLE RES .....
Performance Symbols:
A...General B...Non-flammable

Z...Low noise
Other... Temperature coefficient
Rated Wattage
CARBON 4.7K J A 1/4W
Read description of the Resistor as follows:
NOTES:
(Example)


Carbon
Metal Film
Oxide Metal Film
Composition
Metal Glaze
Wire Wound
Ceramic
Fusible
