— 21 —
Schematic
Location
Part No.
Description
405 157 0505 TR 2SC536NF-NPA
Q1707 405 011 8401 TR 2SC1740S-Q
405 011 8500 TR 2SC1740S-R
405 011 8609 TR 2SC1740S-S
405 012 2002 TR 2SC1815-GR
405 012 2101 TR 2SC1815-O
405 012 2309 TR 2SC1815-Y
405 020 7501 TR 2SC945A-PA
405 020 7709 TR 2SC945A-QA
405 020 7907 TR 2SC945A-RA
405 151 8705 TR 2SC536NG-NPA
405 157 0505 TR 2SC536NF-NPA
Q1708 405 001 7407 TR 2SA1015-O(SAN)
405 001 7605 TR 2SA1015-Y(SAN)
405 004 3109 TR 2SA564A-Q(CU)
405 004 3208 TR 2SA564A-R(CU)
405 006 1707 TR 2SA933S-Q
405 006 1806 TR 2SA933S-R
405 151 3304 TR 2SA608NF-NPA
406 000 6804 TR 2SA1015-GR(SAN)
Q1709 405 108 4903 TR 2SA1837-LB
Q1711 405 108 5009 TR 2SC4793-LB
Q1712 405 011 8401 TR 2SC1740S-Q
405 011 8500 TR 2SC1740S-R
405 011 8609 TR 2SC1740S-S
405 012 2002 TR 2SC1815-GR
405 012 2101 TR 2SC1815-O
405 012 2309 TR 2SC1815-Y
405 020 7501 TR 2SC945A-PA
405 020 7709 TR 2SC945A-QA
405 020 7907 TR 2SC945A-RA
405 151 8705 TR 2SC536NG-NPA
405 157 0505 TR 2SC536NF-NPA
R001 401 024 9701 CARBON 12K JA 1/6W
R002 401 024 9701 CARBON 12K JA 1/6W
R003 401 256 3805 MT-GLAZE 1.5K JA 1/10W
R004 401 256 3805 MT-GLAZE 1.5K JA 1/10W
R008 401 026 9907 CARBON 4.7K JA 1/6W
★ R009 401 064 5701 OXIDE-MT 1.8 JA 2W
★ R010 401 064 5701 OXIDE-MT 1.8 JA 2W
R011 401 026 3905 CARBON 330 JA 1/6W
R012 401 027 2600 CARBON 5.6K JA 1/6W
★ R106 401 008 2001 CARBON 18K JA 1/2W
R107 408 047 6205 ZENER DIODE MTZJ36A (36V)
R131 401 256 0408 MT-GLAZE 12K JA 1/10W
R133 401 256 3805 MT-GLAZE 1.5K JA 1/10W
R135 401 255 6500 MT-GLAZE 100 JA 1/10W
R137 401 150 6209 MT-GLAZE 1K JA 1/10W
R142 401 026 4605 CARBON 33K JA 1/6W
R143 401 150 6209 MT-GLAZE 1K JA 1/10W
R151 401 152 3206 MT-GLAZE 330 JA 1/10W
R161 401 150 5806 MT-GLAZE 100K JA 1/10W
R162 401 150 5806 MT-GLAZE 100K JA 1/10W
R163 401 256 0002 MT-GLAZE 120 JA 1/10W
R164 401 150 6209 MT-GLAZE 1K JA 1/10W
R166 401 162 3609 MT-GLAZE 470 JA 1/10W
R167 401 256 2907 MT-GLAZE 150 JA 1/10W
R201 401 026 9600 CARBON 470 JA 1/6W
R208 401 024 7004 CARBON 1K JA 1/6W
R209 401 024 6700 CARBON 100 JA 1/6W
R212 401 256 7100 MT-GLAZE 680K JA 1/10W
Schematic
Location
Part No.
Description
Tolerance Symbols:
A...0.05% B...0.1% C...25%
D...0.5% F...1% G...2%
J...5% K...10% M...20%
P...+5 -15%

Rated Value, ohms:
K...1,000 M...1,000,000
Material:
CARBON .............
MT-FILM ..............
OXIDE-MT ...........
SOLID ..................
MT-GLAZE ...........
WIRE WOUND .....
CERAMIC RES ....
FUSIBLE RES .....
Performance Symbols:
A...General B...Non-flammable

Z...Low noise
Other... Temperature coefficient
Rated Wattage
CARBON 4.7K J A 1/4W
Read description of the Resistor as follows:
NOTES:
(Example)


Carbon
Metal Film
Oxide Metal Film
Composition
Metal Glaze
Wire Wound
Ceramic
Fusible
