— 30 —
PICTURE TUBE SOCKET BOARD
COMPONENT AND TESTPOINT LOCATIONS (Cont.)
PIC TUBE SOCKET BOARD
COMPONENTS
Part
Q701
Q702
Q711
Q712
Q721
Q722
Q1706
Q1707
Q1708
Q1709
Q1711
Q1712
