— 5 —
Table 1. ON-SCREEN SERVICE MENU
When IC802 (EEPROM) is replaced, check the bus data to confirm they are the same as below. The shaded menu should be
checked and be set up or readjusted according to the procedures described in the following pages. Initial Setup Data marked
with an * should be changed from Initial Reference Data. (See pages 3 and 4 for Initial Bus Data Setup.)
No. TITLE
INITIAL REFERENCE INITIAL SETUP INITIAL SETUP
FUNCTION
DATA HEX DATA HEX DATA BINARY
100 PRGBON4DL2ES1SF FD FD 11111101 PIC+R+G+B On(7~4), D COL(3~2), ES1(1):0(fixed), SF(0)
101 BLKBTM 00 00 00000000 BLK_BTM(1~0)
102 SHU2PO 23 37* 00110111 SUB HUE(7~2), PRE/OVER(1~0)
103 SCL2CTI 11 29* 00101001 SUB COLOR(7~2), CTI_LEV(1~0)
104 ↓↓↓↓NOT USED
105 SSH2LTI 89 61* 01100011 SUB SHARPNESS(7~2), LTI_LEV(1~0)
106 RD2PTL 7C 7C 01111100 R_DRIVE(7~2), PLIMIT_LEV(1~0)
107 GD2ABLM 7F 7F 01111111 G_DRIVE(7~2), ABL_MODE(1~0)
108 BD2CTIM1 7C 7C 01111100 B_DRIVE(7~2), CTI_MODE(1)
109 SBR2GAM 29 32* 00110010 SUB_BRIGHT(7~2), GAMMA(1~0)
10A RCT2LTIM1 58 84* 10000100 R_CUTOFF(7~2), LTI_MODE(1)
10B GCT2DPL 1D 4D* 01001101 G_CUTOFF(7~2), DPIC_LEV(1~0)
10C BCT2DCT 35 8D* 10001101 B_CUTOFF(7~2), DC_TRAN(1~0)
10D SCO4LR2L 57 57 01010111 SUB_CONT(7~4), LRGB2_LEV(3~0)
10E PABL4ABLT F1 F1 11110001 P_ABL(7~4), ABL_TH(3~0)
10F CB0F2AW1AB 94 9C* 10011100 CB_OFFSET(7~2), AGING_W(1), AGING_B(0)
110 CROF2SYS B8 AC* 10101100 CR_OFFSET(7~2), SYSTEM(1~0)
111 YOF4VD2VF 02 0E* 00001110 Y_OFFSET(7~4), VM_DLY(3~2), VM_FO(1~0)
112 RYR4RYB 88 88 10001000 R-Y/R(7~4), R-Y/B(3~0)
113 GYR4GYP 88 88 10001000 G-Y/R(7~4),G-Y/B(3~0)
114 VML4FLC2FLS F2 F2 11110010 VM_LEV(7~4), FLCOL(3~2), FLCOL SW(1)
115 UBK4LBK 00 00 00000000 UP_BLK(7~4), LO_ BLK(3~0)
116 VS 72 72 01110010 V_SIZE(7~2), bit1:1 bit0:0 (b1/b0: fixed)
117 VPS 64 64 01100100 V_POSITION(7~2)
118 VLI4SCR 63 72* 01110010 V_LIN(7~4), S_CORRECTION(3~0)
119 HSI2UUC 70 AC* 10101100 H_SIZE(7~2), UP_UCP(1~0)
11A PAP2LUP 94 5C* 01011100 PIN AMP(7~2), LO UCP(1~0)
11B UCP2UUG 9C 80* 10000000 UP_CPIN(7-2), UP_UCG(1-0)Y
11C LCP2LUG A8 70* 01110000 LO_CPIN(7-2), LO_UCG(1-0)
11D PPH2UPO1VBS 55 69* 01101001 PIN_PHASE(7-2), UC_POL(1), VBLK_SW(0)
11E HPO2CSH1NIN 95 5D* 01011101 H_POSITION(7-2), CLP_SHIFT(1),NONINTER(0)
11F ABO2RAM 81 81 10000001 AFC_BOW(7-2), RF AFC_MODE(1-0)
120 AAN2AGS1 7C 64* 01100100 AFC_ANGLE(7-2), AGC_SW(1)
121 LBK2CPH BC BC 10111100 LEFT_BLK(7-2), CLP_PHASE(1-0)
122 RBK2CGA1HSW 9D 9D 10011101 RIGHT_BLK(7-2), CLP_GATE(1), HBLK_SW(0)
123 VAS2JSW 00 00 00000000 V_ASPECT(7-2), JMP_SW (0)
124 VSR 7D 7D 01111101 V_SCROLL(7-2), b1 : 0, b0 : 1 (b1 / b0: fixed)
125 UVL4LVL 00 00 00000000 UP_VLIN(7-4), LO_VLIN(3-0)
126 VCP4HCP 76 87* 10000111 V_COMP(7-4), H_COMP(3-0)
127 ATI3HVS2BOF1AOF 70 70 01110000 AKB-TIM(7-3), HVBTM_SW(2),BLK OFF(1), AKB OFF(0)
128 128 00 00 00000000 PRELIMINARY
129 RF-SF0 01 01 00000001 RF SHP_F0(0)
12A 4I-SF0 01 01 00000001 480I SHP_F0(0)
12B 4P-SF0 01 01 00000001 480P SHP_F0(0)
12C 1I-SF0 01 01 00000001 1080I SHP_F0(0)
12D H-SF0 01 01 00000001 HDMI SHP_F0(0)
12E D-SF0 01 01 00000001 DIGITAL SHP_F0(0)
12F RF-CON 00 00 00000000 RF CONTRAST
130 4I-CON 00 00 00000000 480I CONTRAST
131 4P-CON 00 00 00000000 480P CONTRAST
