Using the Battery
Installing the Battery
1. Insert the battery into the opening on the back of the phone
at a 45-degree angle, making sure to line up the gold contacts.
Gently press down until the battery snaps into place.
2. Install the protective cover by lining up the tabs at a 45-degree
angle, and gently press down until the cover snaps into place.
Removing the Battery
Warning! Do not handle a damaged or leaking Li-Ion battery as you can
be burned.
1. Make sure the power is off so that you don’t lose any stored
numbers or messages. Remove the protective cover by
pressing the release latch and pulling up on the back of
the cover.
2. Use your thumbnail to lift and then remove the battery as
indicated in the diagram.
8
