Table 5 Video & audio signal formats of digital HDMI
No. Item Unit Parameter Note
1 Video
Deep color：RGB 4:4:4（24 bit/pixel，30 bit/pixel，36 bit/pixel）、
YUV 4:4:4 （24 bit/pixel，30 bit/pixel，36 bit/pixel）、
For "1080p，deep color＂， only support "30 bit/pixel"
YUV 4:2:2(16 bit)、YUV 4:2:2(20 bit)、YUV 4:2:2(24 bit)
2
Audio sample
freqence
kHz
32、44.1、48
3
Audio data
width
Bit
16、20、24
5.7 Music port （depending on different models whether contain the port or not）
Input audio signal to side music port (analog audio input) from audio output equipment, check
audio output.
5.8 Other functions check
a) Check timing on/off, sleeping time off, picture/sound mode, OSD, stereo, digital audio port,
etc,;
b) Check pure digital audio programs (RADIO) ;
c) Check logical channel number (LCN);
d) Check HDMI ARC;
e) Check HDMI CEC;
f) Check OAD for special customer;
6 User Menu Setting before shipment
Enter into Factory Menu and choose “Shipment” to perform presetting before shipment;
Main procedures are described as follow:
a) Clear out all programs;
b) Clear out information of VCHIP，parent control, etc.;
c) Default user analog parameter setting;
d) Recover default password;
e) Set Menu Language as English；
f) Set Power mode as Off。
