APPENDIX-A: Main assembly 9250KI7010 LCD-50XR12F
NAME NO. MAIN COMPONENT AND IT'S NO.
Main processing
board
XI6KI0360110
N101
N104, N107
N106
N205
N606
MSD309PX-LF-SV (5270309003)
NT5TU32M16DG_AC(5273216001)
APX810-29SAG-7 (5270810002)
XC5200C (5275200002)
APA3160 (5273160001)
IR board
XI635KI02705
Key board
XI635KI03200
Power board
XI6KI0362010
Remote control
XI6011300401 RC-1304-0A
Panel
XI5203508501 V500HJ1-L01
