1. DISASSEMBLY
1-1. REMOVAL OF COVER, CABINET AND BOARD LOCATION
1. Pushing the cabinet top
2. Dec cover
3. Screw 3 x 6
4. Spacer sheet inner
Start affixing the sheet from
the center of the mark on
the cover inner.
5. Cover inner
6. Cabinet top
7. Pushing the button slide
8. Screw 3 x 6
9. Screw 3 x 6
10. Screw 3 x 6
11. Special washer
12. Pipe
13. Two screws 3 x 6
14. Two special washers
15. Two pipes
16. Arm. tilt
CA-1 board
VA-10T
(OPTION)
CA-3 board
CA-2 board
CA-4 board
4
1
5
2
3
h
su
P
6
7
9
10
11
15
13
13
16
12
14
14
15
8
