Example: Totalizing weight values
Parameter settings:
Applic.: Total: Comp.Prt: On (menu code 2. 6. 1. 2)
Step Key (or instruction) Display/Data output
1. Tare the balance/scale
w 0.0 g
2. Place sample balance/scale +
380.0 g
(in this example: 380 g)
3. Store value in memory
u + 380.0 g
*
Comp 1+ 380.0 g
4. Remove sample + 0.0 g
*
5. Place the next sample on the
balance/scale (in this example, 575 g) +
575.0 g
*
6. Store value in memory u + 955.0 g
*
+ 575.0 g
*
Comp 2+ 575.0 g
7. View the value in totalizing memory b + 955.0 g
G
*
8. Weigh in further components Repeat steps
as desired 5 and 6
9. Print total weight and
c 0.0 g
clear the totalizing memory
S-Comp+ 2117.5 g
37
