SAS MULTI Series User Manual

No. Parameter Unit SAS MULTI
1. Boiler power kW 17 23 29 36 42 48
2.
Boiler heated surface
m
2
1.5
2.0
2.5
3.0
3.5
4.0
3.
Boiler efficiency
%
80,4 ÷ 85,2
4.
Fuel consumpcion*
kg/h
1,1
1,9
2,5
3,0
3,6
4,1
5. Load chamber capacity
dm
3
kg
120
~90
150
~110
170
~125
170
~125
200
~150
240
~170
6.
Boiler water capicity
l
85
105
115
125
145
175
7.
Boiler weight (without water)
kg
420
550
590
630
670
730
8. Required chimney draught mbar 0,30 0,45
9.
Exhaust temperature
°C
90 ÷ 210
10.
Recommended heating water working temp.
°C
60 ÷ 80
11.
Maximal allowable working temperature
°C
85
12.
Maximal allowable operating pressure
bar
1,5
13.
Minimal return wa
ter temp.**
°C
55
14.
Power supply
V/Hz
~230 / 50
15.
Power consumption
W
t
o 180
16.
Boiler dimensions
A
mm
1140
1140
1160
1160
1200
1280
A1
mm
290
290
305
305
330
330
B
mm
1110
1235
1235
1300
1300
1300
B1
mm
450
535
535
605
605
605
H
mm
143
0
1430
1490
1490
1590
1590
H1
mm
1300
1300
1375
1375
1475
1475
H2
mm
980
980
1050
1050
1120
1120
H3
mm
150
150
150
150
150
150
Combustion chamber dimensions
C
mm
330
330
330
330
330
410
D
mm
260
260
300
300
400
400
17.
Smoke conduit diameter
mm
Ø 180
Ø 180
Ø 200
Ø 200
Ø 220
Ø 220
18.
Connector pipe diameter (supply/return)
"
G 1½
G 2
19.
Min. chimney height
m
6
7
8
9
20. Minimal chimney dimensions/diameter
cmxcm
mm
18x18
Ø 210
20x20
Ø 220
21x21
Ø 240
22x22
Ø 250
25x25
Ø 280
25x25
Ø 280
*
when working at average load (50% of rated power)/ rated load
** if manufacturer recommendations regarding heating water temperature ranges are not observed, boiler must be obligatory connected to central heating system equipped with
three- or four – ways valve, protecting against so called „ low temperatures corrosion”
TECHNICAL AND OPERATING PARAMETERS OF SAS MULTI BOILER

SAS MULTI Series Specifications
