Sase SC12E - Page 29

Item No Part Number Description Quantity
1
SC.12.401 SHAFT, HEX DRIVE 1
2
SC.12.402 FLANGE, BEARING 1
3
SC.12.403 PULLEY, LOWER TOOTHED 1
4
SC.12.404 BEARING, DRIVESIDE 6307 2RS 2
5
SC.12.405 RING, BEARING 1
6
SC.12.410 RING, RETAINING M80 X 2.5 1
7
SC.12.407 KEY, HEX SHAFT 10 X 8 X 40 1
8
SC.12.408 NUT, SHAFT KM 7 1
9
NB.30.210 WASHER, LOCK M10 4
10
NB.10.110 SCREW, ALLEN M10 X 25 4
11
SC.12.406 RING SPACER 1
12
NB.30.219 WASHER, SAFETY MB7 1
13
SC.12.409 O-RING 1
14
SC.10.204 MOUNT, RUBBER 4
15
SC.10.205 SLEEVE, CLAMPING 4
16
SC.10.204 MOUNT, RUBBER 4
List of Items for Hex Drive Shaft
