Sase SC12E - Page 33

Parts for Depth Adjuster
Number Part Number Description Quantity
1
NB.20.130 NUT, ACORN M8 1
2
NB.30.111 WASHER, FLAT M8.4 X 25 X 2 1
3
SC.10.308 GRIP, ADJUSTMENT STAR 1
4
SC.10.307 BUSHING 1
5
794.72.48 BUSHING, GLACIER FMB 1209DU 2
6
SC.12.306 PART, SQUARE 1
7
NB.70.113 KEY, 4 X 4 X 16 1
8
SC.12.305 SPINDLE, ADJUSTING 1
9
SC.10.301 HANDLE, DEPTH CONTROL 1
10a
NB.50.141 PIN, CYLINDER M6 X 50 1
10b
NB.50.142 PIN, CYLINDER M8 X 50 1
11
NB.75.71 ROLLPIN, M3 X 26 2
12
SC.12.302 LEVER, ADJUSTING 1
13
SC.10.313 SPRING, COMPRESSION 1
15
SC.12.303 ROD, DEPTH ADJUSTING LEVER 1
16 SC.12.312
ELEMENT, TOOTHED
1
17 NB.50.136
ROLLPIN, M6X30
1
18 SC.12.320
BUSHING, BRASS
1
19 SC.12.314
DRIVER
1
21 SC.12.317
ROD
1
25 NB.20.116
NUT, HEXAGONAL M16
1
