Item No Part No Description Quantity
1 NB.10.114 M8 X 20 Hex Screw 1
2 NB.30.403 M8 X 30 Fender Washer 1
3 SC.08.000 Black SC8E Scarifier Chassis 1
4 SC.08.113 Upper Toothed Electric Pulley FR200 1
5 SC.08.117 Short T-bolt FR 200 8
6 SC.08.120 Mounting Pair Rail FR200 1
7 SC.08.121 Electric Mounting Plate FR200 2
8 ZZ.L3515T Electric Motor 1 Phase 230V FR200 SC8E 1
Emergency Bracket
9
NB.19.101 8-32 X 3/4 Pan Head Screw 2
10
NB.20.133 8-32 Nyloc Nut 2
11
795.00.76 Mounting Emergency Stop Bracket FR200 1
Dead Man's Switch & Wiring
12 795.00.04 3/4" Liquidtight Flexible Non-metallic Conduit 4 ft
13 795.00.05 3/4" L/T Bullet Connector LT75P 1
14 795.00.06 3/4" W/R Black SLRN21 1
15 795.00.08 3/4-IN 45 L/T Bullet Connector 3
16 795.00.10 18 Yellow Gauge Wire Nut 1
17 795.00.12 Black Zip Tie 11" X 0.125" 1
18
795.00.19 Emergency Stop Switch Tether with Cord 1
19
795.00.22 22-18 AWG Butt Connector Red Vinyl 2
20
795.00.23 3/8" Heat Shrink Tubing Black 4 in
21
AIW.10X3CRD Power Cord 10/3 6 ft
22
AIW.16X2CRD Power Cord 16/2 1 ft
23 MCC.27.16A 16 Amp Switch
1
24
MCC.27.25AA220
Shunt Relay Module for 220 V 1
25 MCC.27.KAZ Switch Enclosure Box for 25A Switch 1
26
NB.19.101 8-32 X 3/4 Pan Head Screw 2
27
NB.20.133 8-32 Nyloc Nut 2
*drill and tap
*Black = 1+5 White = 4+8
SC8E 230V Single Phase
SC.08.042
