List of Items for Housing, Front Wheel, Dust Shield
Number Part Number Description
Quantity
1 SC.08.207 HOUSING 1
2 SC.08.208 BUSHING, CENTERING 2
3 SC.08.116 T-BOLT, LONG (FOR GAS ENGINE) 4
Not shown SC.08.117 T-BOLT, SHORT (FOR ELECTRIC MOTOR) 8
Not shown SC.08.120 RAILS, MOUNTING FOR ELECTRIC MOTOR 1 SET
4 NB.30.118 WASHER, FLAT M8 4
5 NB.30.212 WASHER, LOCK M8 4
6 NB.20.114 NUT, HEXAGONAL M8 4
7 SC.08.901 WHEEL, FRONT 1
8 NB.10.124 SCREW, HEXAGONAL M8X60 1
9 NB.20.114 NUT, HEXAGONAL M8X.8 1
10 SC.08.900 SHIELD, DUST 1
11 SC.08.902 BAR, CLAMPING 1
12 NB.10.110 SCREW, HEXAGONAL M10X25 2
13 NB.30.120 WASHER, LOCK M10 2
14 NB.30.110 WASHER, FLAT M10 2
