SATEL INT-KLCDK-GR 2
SERVICE (green color) - the LED is blinking when the control panel is in the
service mode (the function is only available to the user to whom a service code
has been assigned).
GROUP (two green color LEDs) - used in graphic mode functions to indicate
which data set is currently displayed. The LEDs can show the number of zones
or outputs, or indicate the appropriate expander bus.
For further information concerning the installation and operation of the keypad please
refer to the
INSTALLER MANUAL and USER MANUAL of the INTEGRA or CA-64 alarm control
panel.
Technical data
Nominal supply voltage (±15%).......................................................................... 12V DC
Maximum current consumption ............................................................................110mA
Average current consumption.................................................................................30mA
Operating temperature range ................................................................... -10°C…+55°C
Housing dimensions (width x height x thickness).................................. 160x126x38mm
The latest EC declaration of conformity and product approval certificates
are available for downloading on website www.satel.pl
SATEL sp. z o.o.
ul. Schuberta 79
80-172 Gdańsk
POLAND
tel. + 48 58 320 94 00
info@satel.pl
www.satel.pl
