IRD 810 / 820
IRD 810 AND 820 DETECTORS
NORMAL VERSION
ORDERING INFORMATION
ITEM DESIGNATION ITEM NO.
Flame detector IRD 810 16001
Flame detector IRD 820 16201
Flame detector IRD 810 Industrial 16002
Flame detector IRD 820 Industrial 16202
Flame detector IRD 810 110 volts 16021
Flame detector IRD 820 110 volts 16221
Flame detector holder FZ Holder M 68 59068
Flame detector holder FZ Holder M 74 59074
Flame detector holder FZ Holder M 75 59075
Holder Industrial, UVZ + FZ 18807
The above ordering information refers to the standard version.
Spezial versions are also included in our product range. Specifications subject to change without notice.
M 74 DETECTOR MOUNT
NORMAL VERSION
2
8
ø 6,3
40
50
3
35
ø14
+0.05
0
4.5
26
4
7
ø20
48
IRD 810 AND 820 DETECTORS
INDUSTRIAL VERSION
DETECTOR MOUNT
INDUSTRIAL VERSION
26
30.5
42
75
96
138
22
R 40
30
10
48
36
22
8
4
