Your vehicle’s instrument panel is
equipped with this cluster or one very
similar to it. The instrument panel
cluster includes these key
features:
A. Odometer
B. Air Bag Readiness Light
C. Safety Belt Reminder Light
D. Low Fuel Warning Light
E. Fuel Gauge
F. Malfunction Indicator
(Service Engine Soon) Lamp
G. Service Vehicle Soon Light
H. Reduced Engine Power Light
I. Daytime Running Lamps
J. Speedometer
K. High Beam Indicator Light
L. Turn Signal Indicator Light
M. Oil Pressure Light
N. Tachometer
O. Battery Warning Light
P. Engine Coolant Temperature Light
Q. Traction Control Disabled Light
R. Low Traction Light
S. Brake System Warning Light
T. Engine Coolant Temperature
Gauge
U. Change Engine Oil Light
V. Gate Ajar Light
W. Upshift Light
X. Low Coolant Warning Light
Y. Security Light
Z. Antilock Brake System Warning
Light
IMPORTANT: The instrument panel
cluster is designed to let you know
about many important aspects of your
vehicle’s operation. It is important to
read your Owner Manual and become
familiar with the information being
relayed to you by the lights, gauges
and indicators, as well as what action
can be taken to ensure safety and to
prevent damage.
3
See Section 3 of your Owner Manual.
S
T
R
Q
P
O
N
M
L
K
J
E
F
G
H
I
U
V
WX
Y
Z
A
B
C
D
Instrument Panel Cluster
