5. Reinstall the bulb socket by inserting into
the bulb assembly and turning it clockwise
to secure.
6. Reverse the steps to reinstall the headlamp
assembly.
Taillamps, Turn Signal, Stoplamps
and Back-up Lamps
To change a stoplamp/taillamp, turn signal or
back-up lamp bulb, do the following:
1. Open the liftgate. See Liftgate on page 128
for more information.
2. Remove the two
screws from the
taillamp housing on
the inboard side.
3. Pull out the taillamp housing.
4. Disconnect the wiring harness connector
from the taillamp assembly.
A. Stoplamp/Taillamp
B. Turn Signal Lamp
C. Back-up Lamp Bulb
458
