4. Insert a flat blade tool through the opening in
the top. Make sure the tool fits through the
opening in the headlamp bracket lower arm.
5. Push the locking tab toward the rear of the
vehicle with the tool to lift the headlamp
bracket lower arm.
6. Pull back on the front fascia and then pull the
headlamp assembly out from the vehicle. You
may need someone to assist you with this step.
7. Disconnect the electrical connector from the
bulb assembly.
8. Turn the bulb assembly counterclockwise to
remove it from the housing.
9. Replace the old bulb with a new one.
10. Reverse Steps 1 through 8 to reinstall.
333
