Step Step 8
411312www.sauder.com/services
Page 13
å
Carefully turn your unit over onto its front edges.
å
Insert the ADJUSTABLE SHELF (I) between the ENDS (A2 and B2)
to allow for proper space between the ENDS. Then, remove it before
fastening the BACK (E).
å
Unfold the BACK (E) and lay it over your unit. Make equal margins along
all four edges of the BACK (E). Push on opposite corners of your unit if
needed to make it "square".
å
Fasten the BACK (E) to your unit using the NAILS (1N).
å
NOTE: Be sure to tap NAILS into the holes that line up over the SHELF (F).
å
NOTE: A perforation has been provided for access through the BACK.
Carefully cut out the hole if needed.
å
Fasten the BALLASTS (VV and WW) to the BOTTOM (D3). Use two
BLACK 3" PAN HEAD SCREWS (84S).
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
NAIL
(52 used for the BACK)
1N
These holes must line up over the SHELF (F).
BLACK 3" PAN HEAD SCREW
(2 used for the BALLASTS)
84S
Insert the ADJUSTABLE
SHELF (I) between the
ENDS (A2 and B2) to
allow for proper space
between the ENDS.
Then, remove it before
fastening the BACK (E).
E
I
VV
VV
WW
WW
D3
A2
B2
F
Printed
information
must be
facing up.
To Next Page
