Table of Contents Assembly Tools Required
2-3
4-5
6-21
22-24
25-28
29-30
31
Part Identifi cation
Hardware Identifi cation
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
411312 www.sauder.com/servicesPage 2
A2 RIGHT END (1)
B2 LEFT END (1)
C2 TOP (1)
D3 BOTTOM (1)
D50 RIGHT DRAWER SIDE (1)
D51 LEFT DRAWER SIDE (1)
D175 DRAWER BACK (1)
D983 DRAWER BOTTOM (1)
E BACK (1)
F SHELF (1)
H DOOR (2)
I ADJUSTABLE SHELF (1)
J FRONT SKIRT (1)
K SIDE SKIRT (2)
L DRAWER FRONT (1)
M65 DRAWER BRACE (1)
P TOP MOLDING (1)
VV LARGE BALLAST (2)
WW SMALL BALLAST (2)
Part Identifi cation
å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts.
