Fasten the RIGHT END (A) to the TOP (D2). Tighten two
HIDDEN CAMS.
Step 2
411615 www.sauder.com/servicesPage 6
Surface with
HIDDEN CAMS
Unfi nished surface
A
D2
Finished edge
Rounded edge
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
