Step 4
å
Fasten the UPRIGHT (C) to the BOTTOM (F) and TOP (D2).
Tighten four HIDDEN CAMS.
å
Fasten two MAGNETIC CATCHES (X) to the UPRIGHT (C).
Use two BLACK 1-1/8" PAN HEAD SCREWS (FF).
å
Fasten the MODESTY PANEL (G) to the UPRIGHT (C). Use
two BLACK 1-7/8" FLAT HEAD SCREWS (EE).
411615 www.sauder.com/servicesPage 8
C
D2
F
G
X
BLACK 1-7/8" FLAT HEAD SCREW
(2 used for the MODESTY PANEL)
EE
BLACK 1-1/8" PAN HEAD SCREW
(2 used for the MAGNETIC CATCHES)
FF
Surface with HIDDEN CAMS
Arrow
Minimum
190 degrees
Maximum
210 degrees
Surface without
HIDDEN CAMS
