Table of Contents Assembly Tools Required
3
4-5
6-21
22-24
25-28
29-30
31
Part Identifi cation
Hardware Identifi cation
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
A RIGHT END (1)
B LEFT END (1)
C TOP (1)
D2 BOTTOM (1)
D50 RIGHT DRAWER SIDE (1)
D51 LEFT DRAWER SIDE (1)
D175 DRAWER BACK (1)
D983 DRAWER BOTTOM (1)
E BACK (1)
F SHELF (1)
H DOOR (2)
I ADJUSTABLE SHELF (1)
J FRONT SKIRT (1)
K SIDE SKIRT (2)
L DRAWER FRONT (1)
M65 DRAWER BRACE (1)
P TOP MOLDING (1)
V V LARGE BALLAST (2)
WW SMALL BALLAST (2)
Part Identifi cation
å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts.
