Step Step 7
å
Carefully stand your unit upright.
å
Before fastening the DOOR to your unit, be sure the
mounting screw is against the stops as shown in the below
diagram. If it isn't, loosen the mounting screw to slide it
against the stops. Then tighten the mounting screw.
å
Fasten a DOOR (F) to the LEFT END (B2). Use the screws in
the HINGES. See the next step for adjustments.
å
Fasten a PULL (97K) to the DOOR (F). Use two BLACK 7/8"
MACHINE SCREWS (37S).
å
Repeat this step for the other door.
F
B2
BLACK 7/8" MACHINE SCREW
(4 used for the PULLS)
37S
Pro Tip: Lift with your
legs. And, you know,
your arms.
411985www.sauder.com/services
Page 11
Stop
Hinge
Mounting
screw
97K
