Step 6
Page 10
Now might be a
good time to refresh
your drink.
å
Fasten the LEFT END (N) to the TOP (P), BOTTOM (Q),
SHELF (R), VALANCES (W), and SKIRT (X). Use thirteen
1-1/2" FLAT HEAD SCREWS (33).
å
Finish fastening the LEFT END (N) to the SKIRT (X).
Use a 1/2" PAN HEAD SCREW (16) through the ANGLE
BRACKET on the SKIRT and into the LEFT END.
Q
R
W
X
P
N
W
1-1/2" FLAT HEAD SCREW
(13 used in this step)
33
1/2" PAN HEAD SCREW
(1 used in this step)
16
The SAFETY STRAP
on the TOP should
be near the fl oor.
To Next Page
