Step 1
Look for this icon. It means a
video assembly tip is available at
www.sauder.com/service/tips
å
Assemble your unit on a carpeted fl oor or on the empty
carton to avoid scratching your unit or the fl oor.
å
Fasten fi ve ANGLE BRACKETS (22) to the SKIRT (X). Use
fi ve 1/2" PAN HEAD SCREWS (16).
å
NOTE: Be sure the edges of the ANGLE BRACKETS are
even with the edges of the SKIRT.
å
Fasten the MAGNETIC CATCHES (28) to the
BOTTOM (Q). Use four 5/8" PAN HEAD SCREWS (38).
Page 5
22
X
Q
1/2" PAN HEAD SCREW
(5 used for the ANGLE BRACKETS)
16
22
22
28
Some assembly
(and snacks) required.
5/8" PAN HEAD SCREW
(4 used for the MAGNETIC CATCH)
38
To Next Page
