Hardware Identifi cation
å Screws are shown actual size. You may receive extra hardware with your unit.
SILVER 1/2" MACHINE SCREW - 6
38S
METAL BRACKET - 4
4G
BLACK 9/16" LARGE HEAD SCREW - 16
1S
BLACK 1-7/8" FLAT HEAD SCREW - 8
2S
CAM COVER - 24
13P
METAL PIN - 12
1R
HOLE PLUG - 2
41P
BLACK 9/16" FLAT HEAD SCREW - 4
32S
CAM SCREW - 16
8F
WOOD DOWEL - 4
15F
NAIL - 64
1N
HIDDEN CAM - 36
1F
CAM DOWEL - 20
2F
CARD HOLDER - 3
35M
RUBBER SLEEVE - 12
2R
DECORATIVE NAIL - 4
3N
ADJUSTABLE FOOT - 2
34E
WARNING
Never use this furniture with a TV that is
too large or too heavy. Severe injury or
death can occur. The TV and furniture
will be unstable and may tip.
-The TV must less than 50 lbs.
-The base of the TV must be able to sit
completely on this shelf.
Refer to instruction book for complete
safety information.
Note: This is a permanent label. Do not
try to remove. Surface will be damaged.
08/05 2 6 9 2 2 0 269220
WARNING LABEL - 1
1L
(Refer to the last step for proper
location and application)
CARD SHEET - 1
38M
