Sauder Cottage Road 418072 - Preparation and Identification; Assembly Tools Required; Part Identification

Table of Contents Assembly Tools Required
Part Identifi cation
Hardware Identifi cation
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
2-3
4
5-22
23-25
26-28
29-30
31
Part Identifi cation
A RIGHT END (1)
B LEFT END (1)
C RIGHT UPRIGHT (1)
D LEFT UPRIGHT (1)
D48 DRAWER RIGHT SIDE (2)
D49 DRAWER LEFT SIDE (2)
D151 DRAWER BACK (2)
D953 DRAWER BOTTOM (2)
E TOP (1)
F BOTTOM (2)
G OUTER BOTTOM (4)
H LARGE BACK (1)
I SMALL BACK (2)
J BRACE (1)
K RIGHT FRONT LEG (2)
L LEFT FRONT LEG (2)
M RIGHT REAR LEG (1)
N LEFT REAR LEG (1)
O RIGHT MIDDLE REAR LEG (1)
P LEFT MIDDLE REAR LEG (1)
Q DRAWER FRONT (2)
R TOP MOLDING (1)
S BOTTOM MOLDING (4)
T BOTTOM SIDE MOLDING (4)
U END MOLDING (2)
