Sauder Palladia Lateral File - Part Identification Guide; Assembly Process Overview; Required Assembly Tools

Table of Contents Assembly Tools Required
2-3
4-5
6-28
29-32
33-36
37-38
39
Part Identifi cation
Hardware Identifi cation
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
412015 www.sauder.com/servicesPae 2
Part Identifi cation
å While not all parts are labeled, some of the parts will have a label or an inked letter on the ede
to help distinuish similar parts from each other. Use this part identifi cation to help identify similar parts.
A OUTER RIGHT END (1)
B OUTER LEFT END (1)
C3 INNER RIGHT END (1)
D3 INNER LEFT END (1)
D32 LEFT DRAWER SIDE (2)
D33 RIGHT DRAWER SIDE (2)
D61 DRAWER BACK (2)
D729 DRAWER BOTTOM (2)
E2 TOP (1)
F2 BOTTOM (1)
G BACK (1)
H BRACE (1)
I DRAWER FRONT (2)
M26 VERTICAL MOLDING (2)
M63
DRAWER BRACE (2)
(Hidden part usin recycled
material. Color may vary.)
N SKIRT (1)
O FRONT MOLDING (1)
P BOTTOM MOLDING (1)
R RIGHT MOLDING (1)
S LEFT MOLDING (1)
T PLINTH (4)
U HALF DISK (4)
