Sauder Palladia Lateral File - Hardware Identification Guide

Hardware Identifi cation
å Screws are shown actual size. You may receive extra hardware with your unit.
412015 www.sauder.com/servicesPae 4
7F
TWIST-LOCK
®
FASTENER - 12
MOLDING
CONNECTOR - 2
17F
ANGLE BRACKET - 10
27G
FILE GLIDE - 4
5B
29G
SAFETY STOP - 2
20G
DRAWER STOP - 2
KNOB - 4
33K
FILE BAR - 4
1B
DRAWER FRONT
BRACKET - 4
10G
FILE ROD - 4
9B
INTERLOCK TRACK - 1
22G
FILE BRACKET - 4
12B
NAIL - 36
1N
METAL BRACKET - 6
4G
METAL PIN - 4
1R
HIDDEN CAM - 2
1F
CAM DOWEL - 2
2F
(EXTENSION SET SHOWN SEPARATED)
EXTENSION SLIDE - 4
40MC
EXTENSION RAIL - 4
40MA
