Sauder WHISKER - Page 25

å
Fasten the RETAINING BARS (8) to the SLIDING
DOOR (M). Use four 9/16" PAN HEAD SCREWS (13).
å
NOTE: Be sure to position the RETAINING BARS
exactly as shown in the enlarged diagram. They
should overhang the bottom edge of the DOOR.
å
Flip the SLIDING DOOR (M) over.
å
Fasten the LOCK (7) to the SLIDING DOOR (M) as
shown. Use four 9/16" FLAT HEAD SCREWS (20).
M
M
8
9/16" PAN HEAD SCREW
(4 used in this step)
13
F
L
I
P
O
V
E
R
8
7
9/16" FLAT HEAD SCREW
(4 used in this step)
20
429610whiskersupport.com Page 25
STEP 20
