Savant DigiFlow 6710M-22 User Manual

2
Installation Method : Horizontal installation ONLY
Flow Direction : One way
Flow Rate : 1.0 – 15.0 liter/min
0°
30°30°
Max. M3x10mm
4.0 General :
Temperature : 0 to 80℃ (32 to 170 ℉)
Pressure : Max. 6.0 bar (85 psi)
Weight : 140 g (5.38 oz)
Accuracy : +/- 10%
Connection : 3/8 inch BSP male
Materials : Sensor Body : Acetal Copolymer, TICONA M90
Turbine : Acetal Copolymer, TICONA M90
Stick of Turbine : #304 Stainless Steel
O-Ring : EPDM Rubber
Housing : ABS resin
5.0 Operation Guide
5.1 Install Batteries
Slide off the cover case of the battery room, and put into 2 AA batteries. Then slide the cover case
back.
5.2 Connecting Fitting
The specification of the DigiFlow 6710M-22 Mini Flow connectors is 3/8” BSP male. You could
use any 1/4” BSP male connectors.
5.3 Operating
The DigiFlow 6710M-22 Mini Flow will automatically turn on when there is water flowing through
the sensor. It will automatically turn off in 10 seconds when there is no water flowing.
5.4 Display and Mode Selection :
