SBM XD - Product Specification

2
1. PRODUCT SPECIFICATION :
Refer to the rating plate sticked on the side of the heater.
(see example below).
MODEL
XD 8
XD 8 D
XD 10
XD 10 D
XD 12
XD 12 D
XD 16
XD 16 D
P.I.N. 1312 CQ 6090
Class NOx 4
Weight (kg) 5.25 5.75 6.50 7.75
Net calorific value Qn
(kW) Hi
3.30 3.80 5.10 6.80
Combustion air G20
(m
3
/h) G31
3.40
3.10
3.90
3.60
5.30
4.80
7.00
6.30
Required air renewal rate
(m
3
/h)
33 38 51 68
Consumption G20
(m
3
/h)
0.350 0.400 0.540 0.715
Consumption G31
(kg/h)
0.260 0.300 0.400 0.530
