1
©2011 Scaletron Industries Ltd., Plumsteadville, PA Scaletron, Scaletron Sets the Standard In Corrosion Resistance, Model 1020-1, 1020-2, Model 1099, Model 2305, Model
2306, Model 2307, Model 2308, Model 2310, Model 2330, Model 2350, Model 2352, Model 2353, Model 3001, Model 3002, Model 3003, Model 3004, Model 3005, Model 3006,
Model 3050-1, Model 3050-2, Model 4000SS, Model 4010, Model 4020, Model 4021, Model 4030, Model 4040, Model 4040IBC, Model 4041, Model 4042, and Model 4042WB
are trademarks of Scaletron Industries Ltd. Total Electronic System is a service mark of Scaletron Industries Ltd.
PRINTED IN THE U.S.A. MAY 2011.
These instructions generally describe the installation, operation, and maintenance of,
subject equipment. The manufacturer reserves the right to make engineering
refinements that have not been described herein. Should any questions arise that may
not be answered specifically by these instructions, they should be directed to Scaletron
Industries Ltd., or our Sales Agent for a response.
All possible precautions were taken in packaging each piece of equipment to
prevent shipping damage. Carefully inspect each item and report damages
immediately. Report damage claims to shipping agent involved for equipment shipped
F.O.B. job site. Do not install any damaged equipment!
All instructions given on any labels, or attached tags, should be followed.
Carefully inspect all packing material before discarding, to prevent the loss of
accessories, mounting hardware, spare parts, or instructions.
TABLE OF CONTENTS PAGE #
I. GENERAL DESCRIPTION……………………………………………….…....1
II. SPECIFICATIONS…………………………………………………………..2 - 3
III. ASSEMBLY AND START UP INSTRUCTIONS ……………………….3 – 5
IV. GENERAL OPERATION KEYS…………………..………………………5 - 6
V. GENERAL USAGE……………………………………………..…………6 - 11
VI. OPERATOR’S MENU DESCRIPTION………………………………...11 - 14
VII. SET-UP MENU DESCRIPTION………………………………………...15 - 19
VIII. TROUBLESHOOTING…………………………………….….…………19 - 21
IX. WIRING DIAGRAM FOR 4-20 mA HOOK-UP…………………………….22
X. ORIENTATION DIAGRAM…………………….……………….…………….23
XI. BASE INSTALLATION AND ACCESSORY INSTRUCTIONS - attached
on front
I. General Description:
The Model 1099™ Chemical Process Controller provides a means for weighing
chemicals, controlling the processes of batching, filling, emptying containers, and
providing “scada friendly” information. This indicator can be used as the first step
toward an automated system. The Model 1099™ will monitor up to four scale
systems simultaneously and provides the data and ability to record daily usage
reports. The large LED display (0.56” high) provides digital weight. The LCD
display is an alphanumeric display that provides 2 lines of 16 characters for the
menu and options, which is backlit for easy reading. The electronics are housed
in a NEMA 4X, UL approved enclosure. The indicator plugs into a wall power
source and operates on 120/240 VAC, at 50/60 Hz. The Model 1099™ can be
used with all of our electronic scale bases.
Standard parts Available Options
Indicator 4-20mA signals after the first standard
Instruction Manual Set Points: a maximum of four available
