Model 1099™ Pro-Gram™ Guide Serial Ports
II. Specifications:
Channel: 1 – 4 Independent weighing channels with independent input / output
controls
Input: Up to (16) 350 Ohm load cells on each indicator total
Display Units: pounds, kilograms, gallons, and liters
Range: Maximum Reading: 99,999
LED Display: 0.56” high, indicates the numeric result
LCD Display: alphanumeric display, 2 lines of 16 characters, backlit for easy
reading, displays menu and function
Keyboard: 10 Function keys, 10 Numeric keys, Audible and Tactile feedback
Connector: Power cable sealed with plastic strain relief
Enclosure: NEMA 4X, UL Approved Enclosure
Performance: Overall system accuracy 0.1% to 0.25% Full Scale
Power Rating: nominal
Voltage: 120 / 240 VAC
Frequency: 50/60 Hz
Power: 0.10 / 0.05 A
MAINS supply operational range: +/- 10% of Nominal VAC
Battery: Lithium Coin battery (not replaceable in field). Lifespan estimate: 10
years.
Operational Temperature: 0 C - 40 C
Maximum Rated Altitude: 2000 m
Maximum Relative Humidity: 20% to 90% non-condensing
Pollution degree: 2
Weight of Indicator: approximately 7 lbs.
Dimensions of Indicator: 11.31” high, 9.31” wide, 5.43” deep
Recommended Indicator Location: This indicator should be located in a
location that protects the indicator from being soaked with liquids or extreme
weather locations. If the indicator is to be located outdoors, you must make sure
not to exceed the operational temperature range, and it is recommended that you
provide a covering to protect the indicator from the elements. Locations inside
buildings should be at a height that protects it from chemical splashes and wash-
down areas, but still allow for easy operation of keypad.
Please note: It is imperative that you read the instructions in the manual.
Indicator is fully tested and programmed to the corresponding base at the
factory. If you experience a problem with this equipment, please
disconnect all accessories to this equipment to isolate the problem. As we
have taken great care to be sure your equipment is fully functional within
factory specifications before it leaves our facility, it is best to familiarize
yourself with the manual for set-up and operation procedures before you
begin using this equipment. All safety precautions need to be observed for
the safe operation of this equipment. Failure to operate this equipment as
instructed can result in damage to the equipment, and can possibly cause
