15
900
900
360°
NAVN:
STI:
DIMENSION:
MATERIALE:
DATO:
SIGN:
Krog Iversen & Co A/S
DK-5492 Vissenbjerg
©
TG.NR:EMNE:
C:\Working Folder\Designs\Scan 83\90583006.idw
90583006
Opstilling mod brændbart materiale
21-08-2019
BC
Scan 83
VÆGT:
AREAL:
N/A
N/A
1
0
0
100
4
6
7
1
0
0
400
Front 90°
Max 45°
Max 45°
INSTALLATION WITH ROTATING BASE
To ensure optimum function of the rotating solution for the stove, it is important that assembly be performed in a meticulous
fashion by a qualified fitter.
See the separate instructions supplied with the rotating base.
(ACCESSORY)
Flammable material
All distances are in mm
All distances are minimum distances
