TECHNICAL DATA AND DIMENSIONS
Intermittent operation in this context means normal use of
a wood-burning stove. In other words, you should let the fire
die down until only the embers are left before refueling.
This stove is produced in accordance with type approval for
the product, which also covers the product’s Assembly and
Instruction Manual.
The Declaration of Performance (DoP) is available from
www.scan-stoves.com
*
Test in compliance with EN 13240
CO Emission at 13% O
2
*0,08 %
CO Emission at 13% O
2
1017 mg/Nm
3
Dust @ 13% O
2
23 mg/Nm
3
No
x
@ 13% O
2
98 mg/Nm
3
Efficiency 81 %
Energy efficiency index 108
Energy efficiency class A+
Nominel output 5 kW
Chimney temperature EN 13240 227 °C
Temperature in flue conn. piece 280 °C
Amount of smoke 5 g/sek
Sub-pressure EN 13240 12 Pa
Recommended sub-pressure in
connecting piece
16 Pa
Required combustion air supply 14 m
3
/h
Fuel Wood
Fuel consumption 1,6 kg/h
Amount of fuel 1,4 kg
* based on 1017 mg/Nm3
Materials
Steel plate
Cast iron
Galvanised sheet
Vermiculite
Surface treatment Senotherm
Max. wood length (vertical position) 35 cm
Weight Scan 83-1 / 83-2 ca. 117 kg
Weight Scan 83-3 / 83-4 ca. 125 kg
Weight Scan 83-5 / 83-6, soapstones ca. 186 kg
Weight Scan 83-7 / 83-8, soapstones ca. 212 kg
Connecting piece internal diameter 144 mm
Connecting piece external diameter 148 mm
Fresh air connection piece external diameter 100 mm
Approval type Intermittent fuelling*
