Operation Manual VISATRON® VN115/87plus EX 06/2016
Page 13
SCHALLER AUTOMATION D-66440 Blieskastel / Saarland / Germany / Industriering 14 / P.O Box 1280
Industrielle Automationstechnik GmbH & Co. KG Tel. +49(0)6842-508-0 / Fax -260 / eMail: info@schaller.de / www.schaller.de
Caution! The exhaust from the air jet pump must be blown
back into the crankcase. It’s not allowed to blow the air into
the engine room! It could be dangerous for personnel safety,
because of the air-fuel-mixture.
Remote monitoring devices:
The OMD device can be connected to Schaller's monitoring devices Remote
Indicator II to monitor the oil mist concentration and the status of the OMD device
from a safe location as requested by IACS UR M10. The connection to the
monitoring devices is realized by a RS485 two-wire bus.
Figure 4: Optional Remote Indicator II
Additionally Schaller realized an integration of the VISATRON® VN115/87plus EX
into ship automation systems (e.g. Mega-Guard of Praxis Automation).
Thus, the VN115/87plus EX is a further contribution to safety at sea. Our goal is to
avert damage to assets, personnel and the environment.
