11
Average of the analog values measured (V, A and P). To stabilize the displayed values.
The higher the number, more of the measurements are stable – although they will be slow to update.
Settable between 1 and 15 at steps of 1.
Default = 3
Configuration of the first measurement page to be viewed upon start-up. Using the buttons to scroll through displays
the “titles” of the available pages – the same ones that appear when you press the right-hand button in sequence.
Settable on all the available pages. Default = Blackout detection page, if available, otherwise the INFO page.
Setting this at zero disables password protection for programming with the keypad. The same applies for
password protection for programming by remote control. Settable between 0 and 999 at steps of 1.
Default = 0 (disabled)
Resetting the Totalizer of Pressing and holding the right-hand button for more
the Total Active Energy than 4 seconds reset the value
consumed
Resetting the Totalizer of Pressing and holding the right-hand button for more
the Total Active Energy than 4 seconds reset the value
produced
Resetting the Totalizer of the Pressing and holding the right-hand button for more
Total Reactive Energy than 4 seconds reset the value
Resetting the Partial counter Pressing and holding the right-hand button for more
than 4 seconds reset the value
THE WINDOWS BELOW APPLY ONLY TO THE “S” MODELS
Selecting the threshold operation mode. Settable between: Hi=High threshold, Lo=Low threshold and
Off=threshold disabled. If the threshold is OFF, you will not view the following pages.
Default = Hi (high threshold).
Delay time for activation of the output relay (page displayed only if Th1 Sel is not Off)
In seconds. Settable between 0.0 and 25.5 in steps of 0.1. Default = 0.1
Assigning the delay time for activating the threshold (page displayed only if Th1 Sel is not Off)
The delay time is applicable from the start of threshold activation (Off-On) or at the end (On-Off).
Default = Off-On (at the start)
Assigning the size for activating the threshold (page displayed only if Th1 Sel is not Off)
Settable
at: W+, W-, Hz, 3Vf, V12, V23, V31, 3Vn, V1, V2, V3, 3A, A1, A2, A3,An. Default = W+
Regulating the threshold value as a percentage
of the full scale (page displayed only if Th1 Sel
is not Off)
THE WINDOWS BELOW APPLY ONLY TO THE “485” MODELS
Assigning the MODBUS address node number (of the “INFO” page). Settable between 1 and 255.
Default = 1
Configuring the speed of the RS485 serial port (bps).
Settable between 0 and 4 (0=9600, 1=19200, 2=38400, 3=57600, 4=115200)
Default = 4
set-point. If you do not touch the button when you get the last page, normal operation is restored without saving any changes. To make a
change, simply press one of the buttons when the required page appears, respectively: LEFT-HAND button = DECREASES the value;
RIGHT-HAND button = INCREASES the value. At that point (after pressing the button) the display remains steady so you can check the
modification and the value changes by one unit. If you have to modify a value quite considerably, you can press and hold the button for
more than 2 seconds to speed up the process. The longer you hold down the button, the faster you can scroll through the numbers (4
speeds). They are all “roll” values so when you get to the maximum permitted value you restarted from the minimum value, and vice versa.
When you have set the value as required, release the button and wait for over 4 seconds. The pages then continue scrolling and the
modification is automatically saved. Modifiable pages then follow.
indicates you have entered the setting configuration phase.
A password is only requested if NewPassw is set at a value other than 0 (see below).
Select the correct number and wait for the next page. In the case of a missing or incorrect entry, the instrument
returns to normal operation after about 4 seconds.
By pressing a key when this page is shown, all value parameters return equal to the factory programming,
except totalizer resetting one by one.
Select the CT value (/5) in Ampères. Between 5 and 6000 in steps of 5.
Default = 100
Select the voltage full-scale value.
If in direct connection, it must be settable between 87 and 692 at steps of 1 V (default = 400) equal to the rated
value of the phase-to-neutral line voltage.
Program
Mode
Password
000
Default
Param
CT Set
100
VT Set
231
692
400
During configuration, above is the phase-to-phase value settable between 87
and 692, at steps of 1 V (Default = 400). Below is the phase-to-neutral value
settable between 50 and 400 at steps of 1 V (Default = 231)
Average
3
Default
Page
NewPassw
0
R Time->0
80445:21
R Time->0
0:00
34650
W+ 50.0
kWh+ ->0
78973588
kWh+ 0
0
kWh- ->0
1347
kWh- 0
0
kvarh->0
45921
kvarh->0
0
Th1 Sel
Hi
Th1 Dly
0.1
Th1 DD
Off-On
Th1 Src
W+
Node
1
Speed
4
Th1 Val%
W+ 50.0
At the top is the effective value of
the threshold for the selected size.
Settable between: 0.0 and 100.0,
in steps of 0.1.
Default = 50.0(%)
GB
1RAEM4 Impaginato I_GB_SPA:1 11-02-2009 17:37 Pagina 11
