Schaudt Electrobloc EBL 99 K Series User Manual

Instructio n Manu al for Electrobloc EBL 99 K / EBL 99 K with OVP
3
Date: 20.01.2010
811.419 BA / EN
2Introduction
Y This device is intended solely for use in vehicles.
This instruction manual contains important information for safe operation of
the device. Ensure you read and follow the safety instructions provided.
The instruction manual should be kept in the vehicle at all times. Ensure that
other users are made aware of the safety regulations.
Y This device is not intended to be used by persons (including children)
with limited physical, sensory or mental aptitude or lack of experience
and/or knowledge unless they are supervised by a person responsible for
their safety or have received instruction from this person as to how the
device is used.
Children are to be supervised so as to ensure they do not play with the
device.
3Operation
The electrobloc is operated solely via the IT ... / LT ... control and switch pa-
nel connected. .
No operation of t he EBL 99 K or EBL 99K with OVP electrobloc is required
for daily use (exception: t he battery cut-off switch should be disabled when
the vehicle is not in use, see Section 3.4).
One-off settings only have to be configured when the battery type is chan-
ged (lead-acid or lead-gel), during initial start-up or when retrofitting acces-
sories ( see Section 3.2 and the assembly instructions).
The EBL 99 K with OVP electrobloc is suitable for all applications in which
the danger of overvoltage is especially large. For example, lightning strikes
to the national grid, generator operation, poor electronic installations or trips
to distance countries.
For t his, an overvoltage protection unit is fitted in the electrobloc between
the mains connection and the charge module.
3.1 Starting up the system
Y ATTENTION!
Incorrect electrobloc settings.
Damage to connected devices. Therefore prior to starting:
F Ensure the leisure area battery is connected.
F Ensure that the battery selector switch (Fig. 3, Pos. 10) is set to the
correct position for the battery installed.
³ Turn the battery cut-off switch (see Fig. 3, Pos. 12) to ”On”.
³ Use the main 12V switch (see instruction manual of relevant control and
switch panel) to switch on/off all the consumers and the control and
switch panel.
Overvoltage protection
OVP
