MH-SERIES
Before starting the installation, make sure that
the power supply and all other connecting
cables are voltage-free!
NOTICE
Your thermostat is suitable for installation within a standard 86mm pattress box or European 60mm pattress
box.
Step 1
Keep power o.
Step 2
Remove the mounting Plate by rotating the LCD part.
Step 3
Connect power supply, with the appropriate terminals.
Installation
