14 15
Keep people away from the movement range of the roller shutter system� The
movement range of the roller shutter system must be completely visually accessible
during the operation� Risk of injury�
Children must not be allowed to play with the product�
EU DECLARATION OF CONFORMITY
The belt winder (item no�
DE
22735, 22637) meets the applicable require-
ments of European and national regulations� Conformity has been demonstrated�
The full EU Declaration of Conformity document can be found at:
http://www.schellenberg.de (under ‘Download-Center’, in the ‘Service’ tab)�
Do not discard with household waste! The product is recyclable and can
be returned to a recycling centre or other household electrical waste
collection point
Machinery Directive
2006/42/EC
EMC Directive
2014/30/EU
RoHS Directive
2011/65/EU
INTENDED USE
The product is exclusively designed for controlling shutter systems�
The roller shutter system and its parts must be in a perfect condition� Defects in the
system or its parts must be repaired before installing the product�
An easily accessible 230 V AC / 50 Hz mains socket outlet must be available at the
place of installation (see page 206)�
The surface where the product is to be installed must be level�
Only use original spare parts to avoid product malfunction or defects�
Improper running of the belt (belt guiding) may destroy the shutter belt and cause
unnecessary strain on the product� Install the product such that the belt enters the
shutter belt drive as vertically as possible� This will avoid unnecessary friction and
wear�
