15
GB
not intended use�
Alfred Schellenberg GmbH shall not be liable for any consequential damage, pro-
perty damage and personal injury due to improper use�
According to EN 13659, it must be ensured that the displacement requirements as
per EN 12045 are met� When unrolled, the displacement at the lower edge must be
at least 40 mm at an upward-directed force of 150 N� It must be ensured that the
travel speed of the hanging must be less than 0�2 m/s in the last 0�4 m�
IMPROPER USE
The use of the product for applications other than the aforementioned is not permit-
ted�
Using this product outdoors presents a risk of death from short circuit or electric
shock�
Never install or operate the product outdoors�
Mechanical locks of any kind are not suitable for automated operation with this
product�
TECHNICAL DATA
Item number 22735/22637
Power supply operating voltage 230 V AC / 50 Hz
Rated output 29 W, max. 45 W short term
Standby output approx. < 0.7 W
Power supply output 24 V DC / 1.2 A
Torque MdN = 2.5 Nm
Max. speed 34 rpm
Max. roller shutter blind surface 4.0 m
2
(3 kg/m
2
roller shutter blind
