16 17
TECHNICAL DATA
End pulling force 7 kg on belt
Short-term operation 5 minutes
Protection class II
Protection class
Positioning precision 5 mm
Number of switching times
Automatic sunlight control
adjustment range
3,000 to 10,000 lux
Permissible ambient temperature 0-40 °C
Clock accuracy Approx. +/- 1 minute / month
Dimensions See page 186
Permissible belt widths
Belt length
5.5 m for 1.0 mm belt thickness
4.3 m for 1.3 mm belt thickness
Sound pressure level LpA
<_
Note:
belts with the dimensions mentioned above� Wrong shutter belt lengths and widths will result in damage�
Replace the old shutter belt when the requirements are not met�
